Agathos Barn House

Dimensions:

• 6.00 × 4.00 m (24 m²)

Construction & Envelope

• External wall build-up (~155 mm): timber studs (4" × 2"), OSB sheathing, 100 mm stone-wool insulation, and a ventilated cavity for air circulation.
• Internal partitions (WC and attic wall): double-sided lining with 100 mm stone-wool thermal/acoustic insulation.
• Roofing: ArmourShield shingle tiles with full waterproofing.
• Flooring: laminate wood (Swiss Krono).

Electrical

• Internal installation including 4 double sockets, 3 switches, 1 main control panel, 1 heater switch, and a smoke detector.
• Upgrade provisions for USB outlets and smart switches.
• LED lighting throughout (interior and exterior).

Plumbing & Bathroom

• Complete internal plumbing installation.
• Bathroom formed with exterior-grade fiberglass-reinforced drywall, full wet-area sealing, and electric ventilation.
• Sanitary ware: toilet bowl, shower enclosure, and sink (all Made in Italy).

Openings & Glazing

• Aluminium frames (series MU2500) with 28 mm I-PLUS Light double glazing.

Fit-Out & Extras

• Compact kitchenette.
• Provision for air-conditioning.
• Wooden deck: 7 m².
• Attic with partition wall and door as per drawings.
• Staircase providing access to the attic.
